FAG
FLEX³PRO FLEYEplus v6.x
The
NEW FAG
FLEYEplus v6.x WORKFLOW AUTOMATION
software update utilizes a micro QR
Code and full relational database to
track the photopolymer sheet through imaging, processing, and
final QC check using the FAG FLEX³PRO
Flexo Plate Analyzer.
Working in conjunction with the ESKO Automation Engine, the QR
code is automatically generated and imaged on the mask. Plate type
definitions are contained in the QR Code used to set the plate
processor parameters. This eliminates the possibility of operator
error when keying in the exposure and processing settings for the
plate.
The Micro QR Code
on the processed plate is automatically recognized by the new FAG
FLEX³PRO software, checking
automatically the XML Interface for updates and setting the
measurement parameters, recording the measured results of dot
area, dot structure, plate thickness, and relief.
Errors in configuration of the FAG
FLEX³PRO due to operator error are
now eliminated.A report is generated and written to the database
and made available to the ERP System via an XML Interface, linking
the plate measurements to the customer and the job.
|
